Product Description

notice ;



1.Really confirm the package no include Sim card,customers need to buy the sim
card in your local market.


2017 Mini pet Dog cat animal gps tracker item tkstar tk911 waterproof IP66 GPS/WIFI/LBS Three position ways Free online tracking


1 SUMMARY

Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any remote targets by SMS or internet. The most advanced technology of GPS and GSM dual positioning.



Content

Specs.

Dim.

62mm x 30mm x 18mm(2.7”*1.4”*0.78”)

Weight

33g

Network

GSM/GPRS

Band

850/900/1800/1900Mhz

GPS sensitivity

-159dBm

GPS accuracy

5m

Time To First Fix

Cold status  45s

Warm status  35s

 Hot status  1s

Car charger

12—24V  input

 5V-1A   output

Wall charger

110-220V  input

    5V-1A  output

Battery

Chargeable changeable 3.7V 500mAh Li-ion battery

Stand by

200hours

Storage Temp.

-40°C to +85°C

Operation Temp.

-20°C to +55°C

Humidity

5%–95% non-condensing




2.Hardware Description


1



INDICATOR LIGHT STATUS

MEANING

Green light -Solid

No GPRS signal

Green light -Flash

GPRS connection

Blue light -Solid

No GPS signal

Blue light -Flash

GPS connection

Note: GSM SIM CARD INSTALLATION GUIDE: Only GSM SIM card works in this model
2
_DSC6656_DSC6660_DSC6663_DSC6664_DSC6653 _DSC6654 _DSC6656-1_DSC6656-2



_DSC6656-4_DSC6656-3
1 (1)-11 (2)-11 (3)1 (4)1 (5)RGTRGT-1
_DSC6661

3.TURN ON THE DEVICE

1. Once the SIM card has been purchased and credit added, unscrew the tracker using the screwdriver to remove the 4 small screws in each corner.

2.  Then, insert the SIM card into the SIM card holder by push the metal piece forward and lifting it up, Place the SIM-card into the card slot, Press the metal piece back into its original position and push the metal piece back into place.

3.  Ensure you place the SIM card with the chip face down and the right way round, clip the holder into place and re-screw up the unit.

4.  Turn on the unit outdoors by pressing the “on/off” button until the indicator is on.

5. In 30 or 60 seconds, the unit will begin to work and acquire the GSM signals as well as the GPS signals. The indicator will keep flashing every 3 seconds when the unit has received the signals.

  When this unit receives GPS signals normally, you can use it and do any setting as the instructions of this manual.





4.SMS TRACKING

 4.1. Call the SIM card phone number in tracker,you will receive a Google Maps link of position,

 or sending message “G123456#” to SIM card phone number in tracker .

   E.g:

3
4.2. Admin number setting (After admin number setting, all SMS operations to the device are under this number only.)
  Command: admin123456 phone number(This phone number is your own mobile phone number , not the SIM card number in tracker .)
  Reply admin ok
E.g admin123456 13265790180

When the unit is in over-speed alarm, shake sensor alarm, or low battery alarm, it will send alert to the admin number.( 13265790180 )
Admin number Canceling:
  Command  noadmin123456
  Reply noadmin ok

4.3. Over-speed Alarm setting( It works only in continuous positioning mode.)
Over-speed Alarm setting:
  Command   speed123456 070 (Suppose speed is 70km/h)
  Reply speed ok
  E.g
When the unit speed is over 70km/h, it will send message “speed alarm!” to the admin number every 5 minutes.
Over-speed Alarm canceling
  Command  nospeed123456
  Reply nospeed ok

4.4. Shake Alarm setting
  Command shock123456
  Message Reply shock ok
  E.g
Note:Pls keep the tracker being stationary for 5 minutes, this function will work.
 The tracker will send SMS “sensor alarm!” to the admin number when the unit get shocked.
Shake alarm Canceling:
  Command noshock123456
  Reply noshock ok

4.5. Device working mode setting
Sleep by time mode setting
  Command  sleep123456 time
  Reply sleep time ok
  E.g

(Tracker only works for 5 minutes after being waked up, and back to sleep mode, GPS shut off, GSM works in low consumption mode. SMS command, calling tracker can wake up the tracker.)


Sleep by shock sensor mode setting: (Factory setting is “Sleep by shock mode“)
  Command sleep123456 shock
  Reply sleep shock ok
  E.g
(No shock for 5 minutes, the tracker will work in “sleep by shock” mode, GPS shut off, GSM works in low consumption. Vibration, SMS, calling can wake up the tracker.)

4.6 Terminal (local) Time Setting(factory setting  GMT 0)
  Command  :timezone123456 local time zone   Rep:time ok!
  E.g: timezone123456 +1     timezone123456 -1    Timezone123456 0



4.7Reset Hardware
  Command:begin123456
  Reply:begin ok
  E.g:

5. EXPLANATION OF PARAMETERS/CODES IN SMS MESSAGE
Pic 1:Replied real-time tracking information under GPS satellites signal.
  Lat:22.63952 lon:114.17122  Positioning of the latitude and longitude values.
  Spd:000  This refers to the device moving speed. The unit is km/h.
T:24/09/15  16:00  real-tracking time, the Default is London time. You can set language and time zone in APP.
Bat:100%  The battery value is between 10% and 100%. Once it is less than 30%, it alarms.
2015070203: Device IMEI No. to log in APP and platform.
Google Link: This is the link to the Google map showing the position of the device.

Pic 2:Replied LBS tracking information without GPS satellites signal.
Lac:27a4 1223:   Real-time LBS positioning data.
T:24/09/15 15:17 LBS positioning time.
 Bat:100%  The battery value is between 10% and 100%. Once it is less than 30%, it alarms.
Last:T:25/09/15 03:04  This is the time when tracker got last GPS signal
Google Link: This is the position of last gps signal appeared
6. 0 START ONLINE TRACKING
Pls activate GPRS by sending command “gprs123456” when the tracker is on, and set APN by following steps.
Every sim card carrier has own APN content, we have two methods to find out apn content : check sim card carrier on internet or put sim card into cell phone to find out APN
Two steps to set apn:
1), Turn on gprs function by sending command “gprs123456”
2),Set apn by sending command “apn123456 content” , “apnuser123456 content” ,“apnpasswd123456 content” pls note the content is from SIM card carrier , there is small blank after 123456 in every command.

6.1 WEB ONLINE TRACKING
  Platform : www.mytkstar.net
  Select “Log in by IMEI” on the bottom of screen
  IMEI No. : on the back side of cover
  Password: 123456
Select “Log in by IMEI” on the bottom of screen
  Server:  www.mytkstar.net
  IMEI : on the back side of cover
  Password: 123456



6.3 Turn on GPRS function by sending command “GPRS123456” to the tracker, and set the APN for the tracker, then its online tracking by APP and platform works.   (if you did it already in 6.0, no need to it one more time )







Package Include:
host *1
collar *1
screwdriver
cable*1
manual*1







HT1B03gFPpXXXagOFbXq
